·QTFPV·01 · TETHERED UAV PLATFORMS
OFC-Tethered
UAV Systems.
Persistent, jam-proof aerial ISR and multi-role capability via fiber-optic tethered multi-rotor platforms. Ground-powered, electronically silent, continuously operating — deployed across Indian Army, Navy, and IAF.
4
PLATFORM VARIANTS
300m
MAX TETHER ALTITUDE
∞
OPERATIONAL ENDURANCE
0
RF ATTACK SURFACE
ISR / SURVEILLANCE PLATFORMS
Persistent aerial surveillance.
No battery. No RF. No limits.
Dedicated ISR configurations prioritise sustained hovering endurance, wide-area sensor coverage, and operational continuity in electronically contested environments where conventional UAVs cannot operate reliably.
·QTFPV·T100
FIELD PROVEN
ISR / SURVEILLANCE · COMPACT
Compact Tethered ISR Platform
Man-portable tethered ISR UAV for rapid forward-area deployment. Two-person setup in under 3 minutes. Optimised for lightweight ISR payload packages in tactically contested environments where speed of deployment is critical.
PLATFORM TYPE
Quad-rotor tethered UAV
TETHER LENGTH
100m standard (150m custom)
MAX PAYLOAD
1.2 kg
GROUND POWER
200–400W (grid or generator)
OPERATIONAL ALT.
Up to 100m AGL
WIND TOLERANCE
Up to 10 m/s
SETUP TIME
<3 min (2-person team)
DEPLOYMENT
Man-portable (single-person carry)
DATA LINK
Single-mode OFC, 1Gbps+
CMD LATENCY
<5ms
RF EMISSIONS
Minimal — SIGINT-resistant
FRAME
Carbon fibre composite
ENV. RATING
IP54
TEMP RANGE
−10°C to +50°C
COMPAT. PAYLOADS
QTFPV-EO-TIR, EO-HD, custom
INDIAN ARMY
INDIAN AIR FORCE
DRDO
Price on request
ISR / SURVEILLANCE · HEAVY-LIFT · FLAGSHIP
Heavy-Lift Tethered ISR Platform
Flagship vehicle-mounted tethered ISR system. Designed for the most demanding extended-duration surveillance missions — multi-sensor payload capable, adverse-weather rated, and cleared through formal Indian defence procurement. Operationally deployed across all three service arms.
PLATFORM TYPE
Heavy-lift hex-rotor tethered UAV
TETHER LENGTH
300m (custom configurations to 500m)
MAX PAYLOAD
3.5 kg
GROUND POWER
400–800W (grid or gen-set)
OPERATIONAL ALT.
Up to 300m AGL
WIND TOLERANCE
Up to 12 m/s (Beaufort 6)
SETUP TIME
<5 min (vehicle-mounted)
DEPLOYMENT
Vehicle-mounted GCS (QTFPV-GCS-M1)
DATA LINK
Single-mode OFC, 1Gbps+
CMD LATENCY
<5ms
RF EMISSIONS
Minimal — SIGINT-resistant
FRAME
Carbon fibre + military-grade aluminium alloy
ENV. RATING
IP54 (IP67 on request)
TEMP RANGE
−20°C to +55°C
DUAL PAYLOAD
Yes — simultaneous EO/IR + secondary
COMPAT. PAYLOADS
EO-TIR, SAR, SIGINT, Comms relay, EW
INDIAN ARMY
INDIAN NAVY
INDIAN AIR FORCE
DRDO
Price on request
·QTFPV·T300
FLAGSHIP · FIELD PROVEN
MULTI-ROLE PLATFORMS
Surveillance. Comms relay.
C2 support. One platform.
Multi-role tethered configurations carry simultaneous payloads — combining ISR with communications relay or electronic support — enabling one platform to perform multiple mission functions concurrently from a single deployment.
·QTFPV·MR200
MULTI-ROLE
MULTI-ROLE · SURVEILLANCE + COMMS
Multi-Role Tethered Platform
Purpose-configured for simultaneous dual-payload operation — persistent EO/IR surveillance combined with active 4G/LTE or tactical VHF/UHF radio relay from altitude. Enables extended-range communications for forward units while maintaining aerial observation.
PLATFORM TYPE
Multi-rotor tethered multi-role UAV
TETHER LENGTH
200m
MAX PAYLOAD
2.5 kg (dual-payload capable)
DUAL PAYLOAD
Yes — simultaneous ISR + Comms
GROUND POWER
300–600W (grid or gen-set)
OPERATIONAL ALT.
Up to 200m AGL
WIND TOLERANCE
Up to 11 m/s
SETUP TIME
<4 min (vehicle-mounted or fixed-base)
COMMS RELAY
4G/LTE, VHF/UHF tactical radio
DATA LINK
Single-mode OFC, 1Gbps+
CMD LATENCY
<5ms
ENV. RATING
IP54
TEMP RANGE
−20°C to +55°C
INDIAN ARMY
INDIAN AIR FORCE
Price on request
MARITIME PLATFORMS
Salt air. High winds.
Congested spectrum. We operate regardless.
Maritime configurations are environmental-hardened for the unique conditions of naval and coastal operations — corrosive salt air, high-humidity, elevated wind loading, and the densely contested RF environment of naval electronics.
MARITIME · NAVAL / COASTAL OPS
Maritime-Rated Tethered Platform
Salt-air hardened tethered UAV system engineered for Indian Navy shipborne and shore-based maritime surveillance operations. IP67 rated, corrosion-resistant construction, Force 7 wind tolerance. Operates completely independently of the congested RF spectrum that naval electronics depend upon — zero interference, zero compromise.
PLATFORM TYPE
Maritime-hardened multi-rotor tethered UAV
TETHER LENGTH
200m
MAX PAYLOAD
2.0 kg
GROUND POWER
300–500W (shore / vessel power)
OPERATIONAL ALT.
Up to 200m AGL
WIND TOLERANCE
Up to 15 m/s (Beaufort 7)
ENV. RATING
IP67 — fully submersible
SALT FOG RATING
Per MIL-STD-810H
HUMIDITY
95% non-condensing
SETUP TIME
<4 min (vessel-mounted or shore)
DATA LINK
Single-mode OFC, 1Gbps+
CMD LATENCY
<5ms
RF EMISSIONS
Minimal — no interference with naval electronics
FRAME MATERIAL
Corrosion-resistant alloy + marine composite
TEMP RANGE
−15°C to +55°C
INDIAN NAVY
Price on request
·QTFPV·MT200
NAVY SPEC · IP67
PLATFORM COMPARISON
Select the right configuration
for your operational requirement.
SPECIFICATION
T100 — Compact ISR
T300 — Heavy ISR ★
MR200 — Multi-Role
MT200 — Maritime
Tether Length
100m (150m opt.)
300m (500m opt.)
200m
200m
Max Payload
1.2 kg
3.5 kg
2.5 kg
2.0 kg
Wind Tolerance
10 m/s
12 m/s
11 m/s
15 m/s
Setup Time
<3 min
<5 min
<4 min
<4 min
Deployment Mode
Man-portable
Vehicle-mounted
Vehicle / Fixed
Vessel / Shore
Dual Payload
—
Yes
Yes
—
Environmental
IP54
IP54 / IP67
IP54
IP67
Comms Relay
—
Optional
Yes (4G/VHF/UHF)
—
OFC Data Link
Yes
Yes
Yes
Yes
Command Latency
<5ms
<5ms
<5ms
<5ms
Service Arm
Army, IAF
Army, Navy, IAF, DRDO
Army, IAF
Navy
Temp Range
−10 to +50°C
−20 to +55°C
−20 to +55°C
−15 to +55°C
Price
Price on request
Price on request
Price on request
Price on request
Discuss your tethered UAV requirement.
Our technical team will help identify the right platform configuration, payload combination, and deployment mode for your specific operational context — under appropriate confidentiality frameworks.
